Ref: 60A-333 – TEAM MECCANICA TD560-7/400-7, 14 Block Steel Rod Drawing Line

Steel Rod Drawing Line
Was until now drawing Inconel 625, 825

Includes:
Two (2) vertical stand coil payoffs
Wire cleaning
Salt bath
Dancer
Drawing Machine
Electrical Controls
Wire Washing
Team Meccanica BU1000/760 1000mm Spooler Take-up

Manufacturer: Team Meccanica SRL
Model: TD560-7/400-7
Year of Manufacture: 2000
Number of Blocks: 14
Block Diameter: First (7) 560mm, Second (7) 400mm
Enter: 5.5mm
Finish: 1.2mm
Speed: 1-3 Meters/second
Block Cooling: Air and Water
Die Holder Cooling: Air and Water
Die Holder Type: Rotating
Motors: 400 Volts, 60 HP, 50 HZ, 1465 RPM ( First 7 Steps), 400 Volts, 40 HP. 50 HZ, 1470 RPM ( Second 7 steps )
