Ref: 50B-242 – Trafalgar, 6+12+1 Wire, Inside String Up Tubular Stranding Line

Inside String Up Tubular Stranding Line

Includes:
Die holder
1200mm dia single wheel capstan with gear box
Cantilever type take-up 2200mm x 1250mm wide (86 inch X 48 inch) with Uhing traverse
Braking system Friction band
Payoff Single bobbin

Manufacturer: Trafalgar
Number of Wires: 19
Configuration: 1+6+12
Reel Dimensions: Flange dia. 400mm (15.75 inch), Width 250mm (9.8 inch), Bore 30mm (1.2 inch)
Bobbin Weight: 150 kg
Line Speed: 32m/min (100 FPM)
Direction: Right to left.
Tube Diameter: 650mm (25.6 inch)

For more pictures, further specifications, questions, or if you cannot find what you are looking for, please contact us.
