Ref: 34-226 – EVG LGR/48, Mesh Welder, 48in Width

Mesh Welder
Machine is in storage. Welder head only.

Manufacturer: EVG
Model: LGR/48
Year of Manufacture: 1993
Wire Diameter Range: 2.5 to 8 mm (.098” to .315”)
Welding Width: 48 inches (1,219.2 mm)
Working Width: 53 inches (length of cross wire)
Line Wire: continuous feed
Cross Wire: feed from pre-straighten and cut.
Supply Voltage: 3 X 440 V, 60 Hz
Rated Power of Welder at 50% Duty Cycle: 600 kVA
Total Driving Power: 60 kW
