Ref: 15-143 – Spirka DFT24-501, 24 Carrier Vertical Braiders
24 Carrier Vertical Braiders
Two (2) machines available
Manufacturer: Spirka
Models: DFT24 and DFT24A
Year of Manufacture: 1998 DFT24A, 1993 DFT24
Number of Carriers: 24
Speed: 20-80 rpm
Bobbin Dimensions: 98 x 100/80 mm (S4)
Bobbin Capacity: 550 cm3
Braid Material: Textile, Cu /Steel (soft)
Wire Diameter: 0.10-0.30 mm
Pull off per Bobbin: Continuous Drive 9-180 mm
Diameter of Pull-off Capstan: 650 mm
Central Passage: 40 mm
Braid Diameter Max: 30 mm
Motor Output: 4 kw
Input: 480 V, 60 Hz
For more pictures, further specifications, questions, or if you cannot find what you are looking for, please contact us.
